Morden Decor Revolution
Hoyah Green Wall Panel
Remove Protective Film in 45 days after Installation
Carbon Crystal Board
Carbon crystal board is one of the most popular wall decoration materials at present, widely used in various commercial spaces, hotels, apartments, schools, hospitals, residences, and other engineering decoration fields.
1.Decorative layer
The decoration layer has a variety of fabrics.
including PVC film, PET film, metal film, water-based cross fabric base film, etc.
2.Co extruded crystal ceramic layer
The crystal ceramic layer adopts an acrylic formula system, which has excellent flatness, hardness, and impact resistance.
3.Bamboo charcoal fiber layer/ecological diatom mud layer
There are two options, one is the bamboo charcoal fiber layer, and the other is the ecological diatom mud layer, Bamboo charcoal fiber laver – The core layer of the substrate is a composite material of PVC resin powder, bamboo charcoal fiber powder, and natural calcium carbonate powder, etc. Ecological diatom mud layer.
Fearture
lt has the following product characteristics:
Installation Distribution Diagram
Installation method, process, and precautions for wood veneer board:
1. First, investigate whether the wall is flat. lf the wall is flat, there is no need to install carbon crystal board/wood veneer board as a base. lf the wall is not flat, it must be leveled with plywood/gypsum board/cement board before installation and bonding.
2. Measure the width of the entire wall to determine the cutting width of each decorative panel during actual installation.Pay attention to the horizontal position of the doors and windows and ensure proper distribution.Generally, for wider walls.1220 large boards are directly used for paving. For narrower walls calculate the actual size, evenly cut the width of the decorative panels, and then fit them together.
3. During actual installation, install the top corner line first, and then install the bottom corner line. Facing the wall, start fitting from left to right. Firstly, use a point like (or S-shaped) structural adhesive and apply it evenly to the wall surface (or back of the decorative panel).Then, insert the decorative panel diagonally into the top corner line, adiust the horizontal position, and then insert the decorative panel from right to left into the left corner line.
4. Slowly flatten the four edges and middle position of the decorative panel with a rubber hammer, and insert a metal l-shaped strip on the right side of the decorative panel, paying attention to the appropriate tightness. Fix the l-shaped strip with grab nails.This cvcle of installation is sufficient.
5. Pay attention to the application scenarios of various metal lines.When measuring the scale, carefully survey and make statistics: when stocking up, based on the number of decorative panels and room structure, prepare a sufficient number of metal lines to avoid errors and delays in installation.
Accessories
L: 1.5cm&1cm
H: 1.5:0.5cm
U: 1.5cm
T: 0.5cm
Wall Panel Series
G118C3-02103
G118B-1338
G118C1-02110
G118B-02140
G118B-7066-1
G118C3-0357
G118C-009-48
G118C-272-4
G118C-0601-17
G118C-6052-17
G118C-7018-1
G118C-7133
G118C-7151-11
G120-06157
G120A-20182-3
G120-02
G120-009-28
G120-009-30
G120-009-27
G120-009-58
G120-011-34
G120-011-90
G120-0030
G120-042-1
G120-0121
G120-0166
Processing
Knife and Measuring tools
Measuring and cutting the board
Silicon Glue Adhesive foam
Fix the board to wall permanently
Double side
Fixing the board on the wall in right positin
Plane
Cutting the edge of board in even
Cutting Machine
Cutting the board in right sizes
Trimming Machine
Notch the back of board, bend it in 90°
Heat Gun
Heating the back of the board to bend it in arc
Aluminum Profile
Connect boards together
About Hoyah
Hoyah Green Wall Panel stands as a leading manufacturer specializing in carbon crystal panels. Since its inception, the Hoyah brand has consistently remained at the forefront of industry development, amassing vast production experience and technological expertise.We are relentless in optimizing our production processes and introducing advanced equipment to ensure that every carbon crystal panel meets the pinnacle of industry standards, catering to the diverse needs of our customers.
Our focus lies in the research, development, production, and sales of high-quality carbon crystal panels. With a professional and comprehensive customer service system, unwavering design innovation capabilities, and impeccable product quality, Hoyah has garnered widespread market recognition and acclaim.Through design innovation and superior quality, Hoyah has established an outstanding brand image within the decorative materials sector.
